Expanding on the popularity and superior performance of our RDX1 charger line, we are proud to introduce the AC input, micro processor RDX1 Mini. Hitec’s sleekly-designed, compact AC charger packs 65 watts of power into a fraction of the size of most chargers to meet your battery management requirements. It is compatible with a full range of the most popular battery types, including the new generation LiHV. With 6 amps of maximum charging current and 2 amps of discharging current, our RDX1 Mini is the next best way to stay charged with Hitec!
Key Features
- User-Friendly LCD Interface
- Stores 10 Different Battery Memory Charge/Discharge Profiles
- Terminal Voltage Control
- Built-in Balance Connector (JST, XT)
- Cell Balancing While Discharging
- Balance, Standard, Fast and Storage Modes for All Lithium Battery Chemistries
- Re-Peak Charge Mode and Delta-Peak Sensitivity for NiMH/NiCd Batteries
- Optional Temperature Sensor for NiCd/NiMH Charging
- Built-in XT60 Connector
- Smart Ventilation Fan
SPECIFICATIONS:
Application AC powered Battery Charger and Balancer
Battery Type 2-4S LiPo, HV-LiPo, LiIon, 6-8 cell NiMH, NiCd, 6-12V Lead Acid, HV-LiPo (3.8V per cell), LiFe (3.3V per cell), LiIon (3.3V per cell), LiPo (3.7V per cell), NiCd (1.2V per cell), NiMH (1.2V per cell), Pb (2.0V per cell)
Height 2.17" (55mm)
Input Voltage 100-240V AC
Integrated Balancing Y - Internal Balancer & Internal Adapter
Length 4.61" (117mm)
Material Plastic case
Maximum Charge Rate 6A
Output Connector XT60
Selectable Charge Rate Yes
Weight .69lbs (315g)
Width 4.17" (106mm)
